180mm Diamond Turbo Cutting Saw Blades for Fast Cutting Reinforced Concrete
1. Description:
180mm Turbo Concrete Cutting Saw Blades are professionally designed for wet or dry cutting reinforced concrete, high quality diamond makes faster cuting and longer cutting life.
2. Specification:
Diameter:180mm
Segment thickness:2.4mm
Segment height:7/10/12mm
Inner hole:16mm, 20mm, 22.23mm, 25.4mm, 50mm, 60mm, 80mm
| Inch |
Diameter
(mm) |
Teeth length
(mm) |
Teeth thickness
(mm) |
Teeth height
(mm) |
Teeth number
(nos) |
| 7" |
180 |
34 |
2.4 |
7/10/12 |
14 |
Other size Concrete Saw Blade we could do as following
| Inch |
Diameter
(mm) |
Teeth length
(mm) |
Teeth thickness
(mm) |
Teeth height
(mm) |
Teeth number
(nos) |
| 4" |
105 |
32 |
2.2 |
7/10/12 |
8 |
| 4.5" |
115 |
31 |
2.2 |
7/10/12 |
9 |
| 5" |
125 |
31 |
2.2 |
7/10/12 |
10 |
| 6" |
150 |
34 |
2.2 |
7/10/12 |
11 |
| 8" |
200 |
40 |
2.4 |
7/10/12 |
13 |
| 9" |
230 |
37 |
2.6 |
7/10/12 |
16 |
| 10" |
250 |
40 |
2.6 |
10/12/15 |
16 |
| 12" |
300 |
40 |
3.0 |
10/12/15 |
20 |
| 14" |
350 |
40 |
3.2 |
10/12/15 |
24 |
| 16" |
400 |
40 |
3.4 |
10/12/15 |
28 |
| 18" |
450 |
40 |
3.6 |
10/12/15 |
32 |
| 20" |
500 |
40 |
4.0 |
10/12/15 |
36 |
| 24" |
600 |
40 |
4.4 |
10/12/15 |
42 |
| 26" |
650 |
40 |
4.4 |
10/12/15 |
42 |
| 28" |
700 |
40 |
5.0 |
10/12/15 |
40 |
3.Feature:
1) High precision and speed for cutting reinforced concrete2) Cutting reinforced concrete is not restricted by the construction site, environmental protection, duration, and other conditions for safety reasons, to break the traditional construction method after removal of gas cutting picks or directional blasting, which does not affect the surrounding normal traffic, short construction period, safety factor advantages.
4. Packing:
Each laser saw blade is packed in white box, then 100pcs put in an export standard carton, gross weight per carton is limited within 13kg.
Shipping date: If there is steel discs in our stock, normally shipment within 7-10days. If not, around 25-30days.
Delivery way: By air, by sea, by land, by courier, etc.
